Solar DC Cable for Photovoltaic Systems
Compare SINELINK solar cable families by standard, voltage context, construction, and application before moving to a detailed product specification.
For EPC contractors and procurement teams, the key question is whether the cable construction, marking, certificate scope and approved use match the project specification and installation conditions.
Solar DC cable is a purpose-designed cable used on the direct-current side of a photovoltaic system, including module interconnection, string wiring, combiner-box connections and inverter DC inputs. Selection should be based on the required product standard, maximum system voltage, corrected circuit current, route length, voltage-drop target, installation environment and exact connector range—not cable size or color alone.
Need a project-specific cable recommendation?
Send the target market, system voltage, circuit current, route length, ambient conditions, installation method, connector model and required certificate.
Solar DC Cable Standards: H1Z2Z2-K, IEC 62930, PV1-F and PV Wire
Start with the destination market and project compliance basis. Product designation alone is not proof of acceptance; confirm the current certificate or listing, manufacturer, construction, size range, and cable marking.
| Designation | Compliance context | Typical voltage context | Procurement decision |
|---|---|---|---|
| H1Z2Z2-K | EN 50618 / certificate scope | Up to 1.5kV DC where certified | Check the EN certificate, manufacturer, size range and exact marking. |
| IEC PV cable | IEC 62930 | Up to 1.5kV DC within the standard scope | Confirm the precise product designation and certificate; do not infer it from catalogue wording. |
| PV1-F | TÜV 2 PfG 1169 family | Product and certificate dependent | Use for legacy or explicitly specified projects after confirming present project acceptance. |
| PV Wire | UL 4703 listing context | Listing and product dependent | Confirm the listing, conductor, wet/dry rating and locally adopted code requirements. |
H1Z2Z2-K is commonly specified for EN-oriented 1500V projects. PV1-F remains relevant where TÜV 2 PfG 1169 is explicitly accepted. IEC 62930 supports IEC-oriented specifications, while North American projects normally require an applicable PV Wire listing. Final acceptance depends on the project specification, local rules, and verified certificate scope.
What to Confirm Before Selecting a Solar DC Cable
Four checks help EPC and procurement teams narrow down the suitable cable family before requesting a detailed quotation.
01
Market and standard
Define the destination country, project standard, and required certification or listing basis.
02
Voltage and current
Confirm maximum DC voltage and corrected current capacity for temperature, grouping, and installation.
03
Cable size and voltage drop
Use the actual route length, complete current path, and loss target instead of selecting 4mm² or 6mm² by habit.
04
Connector, environment and evidence
Verify connector fit, installation exposure, certificate scope, cable marking, and required batch documents.
How Solar DC Cable Is Constructed
A typical IEC- or EN-oriented solar DC cable uses a stranded conductor, cross-linked insulation, and a cross-linked outer sheath. The specific material formulation and performance claims must match the approved product documentation.
1. Conductor: flexible stranded copper or tinned-copper construction as specified.
2. Insulation: electrically separates the conductor and forms part of the certified cable construction.
3. Outer sheath: provides the external protective layer for the product’s approved installation conditions.
Terms such as “XLPO,” “UV-resistant,” or “halogen-free” should not replace the current certificate and technical datasheet.
Common Solar DC Cable Sizes and Supply Formats
Common metric conductor sizes include 2.5mm², 4mm², 6mm², 10mm², 16mm², 25mm² and 35mm². Cable size must be selected by calculation and interface checks, not by project habit.
Single-Core Solar Cable
The standard format for many PV DC circuits, supplied in the confirmed conductor size, jacket color and packing length.
Twin Solar Cable
Bonded conductors can support organized parallel routing where the product approval and termination design permit their use.
Pre-Assembled Harnesses
Cut-to-length assemblies may reduce field termination work after connector, seal, polarity, tooling, and test requirements are approved.
